Home > products > Chemical Fume Hood > Polypropylene Chemical Laminar Flow Hood with Electric Socket for lab testing

Polypropylene Chemical Laminar Flow Hood with Electric Socket for lab testing

Product Details

Place of Origin: CHINA

Brand Name: SOPERSL

Certification: ISO9001

Model Number: PFH6-1200C

Payment & Shipping Terms

Minimum Order Quantity: 5

Price: Negotiation

Packaging Details: crate box

Delivery Time: 20-25 Days

Payment Terms: T/T or L/C at sight

Supply Ability: 1500 per month

Get Best Price
Highlight:

chemical fume extractor

,

chemistry fume hood

Color:
White
Material:
Poly
Air Velocity:
0.5m/s
Sash Window:
5mm Double Layer Tempered Glass
Illumination:
≥450Lux
Color:
White
Material:
Poly
Air Velocity:
0.5m/s
Sash Window:
5mm Double Layer Tempered Glass
Illumination:
≥450Lux
Polypropylene Chemical Laminar Flow Hood with Electric Socket for lab testing

Polypropylene Chemical Laminar Flow Hood with Electric Socket for lab testing



Production Description


  • LCD display screen. See the air velocity directly.
  • The air velocity is adjustable ( 6 levels )
  • Electrical controlled glass.
  • Removable work surface. Easy to clean.

Name

Value

Brand

SOPERSL

Model

PFH6-1200

Base Cabinet

(Optional)

Height is 800mm, the exterior size include the cabinet height

Protection Class

Protection Type

Class I

IP 20

Air Velocity (m/s)

Noise

≥0.5m/s

≤60dB(A)

Pipe Collar

Φ250

Pipe Strap

1pc

Fluorescent Lamp

UV Lamp

36W*1



30W*1

Ext. sizes(L*W*H)

1200×850×2350mm

Work size(L*W*H)

1020×720×750mm

Accessory

Vertical and single test cock: made by brass, the surface is treated by EPOXY baking paint.

Cup slot: acid and alkali resistance, PP water cup.

Sink: PP cup sink.

Socket: multi-functional with splash-proof box and safeguard cover.

Warranty

One year



Application

PFH series Fume hoods are the first defense to minimize dangerous chemical exposure to research workers. They are considered the primary means of protection from inhalation of hazardous vapors.

Competitive Advantage

1. Inner liner panel: polypropylene, acid and alkali resistance, temperature- resistance, anti-moisture
2. Guide plate: polypropylene, reasonable and knock-down guide structure. Concentrated and effective discharge air, letting off different poisonous gas
3. Operation table board: acid and alkali resistance, anti-moisture. Impact resistance



Details:

Polypropylene Chemical Laminar Flow Hood with Electric Socket for lab testing 0



Polypropylene Chemical Laminar Flow Hood with Electric Socket for lab testing 1



Description PFH6-120 PFH6-150 PFH6-180
Overall Size (With Base Cabinet) (H×W×D) 2400x1200x850mm 2400x1500x850mm 2400x1800x850mm
Working Area(H×W×D) 1100x1000x700mm 1100x1300x700mm 1100x1600x700mm
Base cabinet (H×W×D) 850 x1200x850mm
Work Platform Main Unit - 100%, 8 mm PP fabricated.
Construction Material Main Unit - 100%, 8 mm PP fabricated.
Window Made of 5mm tempered glass, max:820mm opening
Power supply
Touch control panel
AC220V10A ON/OFF Switches on front fascia (BL / FL) A fluorescent lamp, fan, the power switch and stand-by switch
Air Flow 100 % Air take from inside room through
Remote control water valve Pure water, tap-water
Remote control air valve One N2 valve, one vacuum valve
Water Tank One
Options and Accessories:

A wide range of configurations to suit any containment application: -

Base Cabinet with chemical storage cabinet (with air vent)

Sink : Molded polypropylene sink with drain nipple

Auxiliary Socket – 5/15 Amp. – As require qty.

Filter chocking alarms , Universal Casters with Brake

OTHER CAPACITY : ON REQUEST
