Product Details
Place of Origin: CHINA
Brand Name: SOPERSL
Certification: ISO9001:2008
Model Number: SBK-ZB
Payment & Shipping Terms
Minimum Order Quantity: 5
Price: Negotiation
Packaging Details: Standard Paper Box on the Plywood Pallet
Delivery Time: 25-30 Days
Payment Terms: T/T or L/C at sight
Supply Ability: 5000 per month
Type: |
Pressure Steam Sterilization |
Chamber Material: |
Medical Stainless Steel 304 |
Applications: |
Microbiology, Medicine |
Power(W): |
2000 |
Display: |
LCD Display |
Color: |
White |
Temp. Range:: |
105-136℃ |
Product Name: |
Laboratory Autoclave |
Water Consumption: |
0.16L~0.18L In One Cycle |
Type: |
Pressure Steam Sterilization |
Chamber Material: |
Medical Stainless Steel 304 |
Applications: |
Microbiology, Medicine |
Power(W): |
2000 |
Display: |
LCD Display |
Color: |
White |
Temp. Range:: |
105-136℃ |
Product Name: |
Laboratory Autoclave |
Water Consumption: |
0.16L~0.18L In One Cycle |
Class B dental/medical autoclave/steam sterilizer
Applcation:
The newly-designed model with opening water tank on the top, strictly meets the standard of EN13060, which makes wash and cleaning much more convenient.
It adopts European B standard with 3-times pre-vacuum preceding vacuum drying. Residual humidity is less than 0.2%. Vacuum measurement reaches-0.8bar.
It sterilizes and sanitizes miscellaneous packed or unpacked medical instruments, Whether solid or A-type hollow, whether with multi-apertures or inset pipes. It efficiently tides air from every hollow area of any hollow instrument, such as hand-piece, making sure that water steam reaches every corner.
Features:
1. Build-in open type water tank
The sterilizer adopts easy-clean open type water tank which can support repeated program running if fully injected with water.
2. High-efficiency ultimate vacuum
The sterilizer adopts high-efficiency low noise vacuum system which has excellent effects.
3. Large LCD display for SBK-Z18/24B
The LCD screen can display temperature, pressure, time, operating status, failure warning and other information.
It is convenient for customers to observe the sterilizer running status.
4. Multiple program types
The system has various programs that include: packed items, unpacked items, custom program,
rapid program, BD testing program, vacuum testing program, preheat program and drying program.
5. Standard USB port for SBK-Z18/24B
Users can store the sterilization data with USB disk.
6. Optional mini printer can be attached to record the process of sterilization.
Fuzzily computer controlled, digital bright show.
The interface is modularized panel for easy operation.
It is installed with BOWIE&DICK which measures the penetration of water steam.
Mini printer can be attached to record the process of sterilization.
| Technical Parameters of SOPERSL Professional Autoclave SBK-ZB | |||||||
| Model | SBK-Z2B | SBK-Z7B | SBK-Z10B | SBK-Z12B | SBK-Z16B | SBK-Z18B | SBK-Z24B |
| Capacity | 2L | 7L | 10L | 12L | 16L | 18L | 24L |
| Sterilization Class | CLASS B | ||||||
| Sterilization Temperature | 121℃,134℃ | ||||||
| Special Program | HIV, HBV long-sterilization program | ||||||
| Dry System | Vacuum drying system | ||||||
| Display | High-light LCD tube display | ||||||
| Testing System | Bowie &Dick Test | ||||||
| Vacuum Test | |||||||
| Helix Test | |||||||
| Control Precision | Temperature: 1℃ | ||||||
| Pressure: 0.1bar | |||||||
| Sterilization Data | Optional Mini printer | ||||||
| Safety System | Relief valve | ||||||
| Hand lock door | |||||||
| Pressure lock system | |||||||
| Pressure or temperature over load protection | |||||||
| Alarm system | |||||||
| Water Supply System | Build-in water tank easy to clean | ||||||
| Tray Holder | SS basket, SS shelf | ||||||
| Chamber | Medical stainless steel 304 | ||||||
| Max working pressure:2.3bar | |||||||
| Min working pressure: -0.9bar | |||||||
| Max temperature: 145℃ | |||||||
| Operation Temperature | 5~40℃ | ||||||
| Noise | <50db | ||||||
| Water consumption in one cycle | 0.12L~0.16L | 0.16L~0.18L | |||||
| Power supply | 110/220V±10%, 60/50Hz | ||||||
| Power consumption | 1200W | 1400W | 1400W | 1400W | 1800W | 1500W | 1700W |
| Chamber Size(mm) | φ88*175 | φ170*320 | φ192*320 | φ192×340 | φ240×360 | φ245×360 | φ245*470 |
| External Size(mm) | 350*284*376 | 540*370*360 | 540*370*360 | 560*450*400 | 445*550*395 | 560*450*400 | 670*450*400 |
| Packing Size(mm) | 415*345*441 | 615*440*425 | 615*440*425 | 660*525*495 | 670*550*500 | 660*525*495 | 770*525*495 |
| Net Weight | 26kg | 37kg | 40kg | 43kg | 47kg | 47kg | 53kg |
About Payment Terms: We accept the following payment methods: T/T, Credit, Escrow.
About Delivery time:
Most of our products on sale are in stock, and will be delivered within 10-15 days. But still please confirm your order and detailed informaion with us.
About Photos: All products' photos are true and taken carefully by our Graphic Designer Team.
About After-Sales Service:
We're focusing on every client's satisfaction.
Professional team will solve any problems you met during the whole purchasing progress.
Package conform to international standards. In general, the package is wooden or carton.
The goods will be delivery within 10-15 work days.
Production, package & transport
