8mm Polypropylene Lab Fume Hood Rust-Resistance Pfh High capacity for corrosive substance

Product Details

Place of Origin: CHINA

Brand Name: SOPERSL

Certification: ISO9001

Model Number: PFH6-1800

Payment & Shipping Terms

Minimum Order Quantity: 5

Price: Negotiation

Packaging Details: crate box

Delivery Time: 25-30 Days

Payment Terms: T/T or L/C at sight

Supply Ability: 1500 per month

Get Best Price
Highlight:

chemical fume extractor

,

exhaust fume hoods

Color:
White
Noise DBA:
≤ 60
Blower:
Built-in Centrifugal Fan
Material:
Poly
Name:
Chemical Fume Hood
Color:
White
Noise DBA:
≤ 60
Blower:
Built-in Centrifugal Fan
Material:
Poly
Name:
Chemical Fume Hood
8mm Polypropylene Lab Fume Hood Rust-Resistance Pfh High capacity for corrosive substance

8mm Polypropylene Lab Fume Hood Rust-Resistance Pfh High capacity







Production Description

  • 8mm.Polypropylene material
  • polypropylene, acid and alkali resistance, temperature- resistance, anti-moisture
  • Easy: install and wash.
  • strong bearing capacity.

Name

Value

Brand

SOPERSL

Model

PFH6-180

Window

5mm PS transparent plate, balancing form elevation and subsidence, it can be stopped at any position by pulling.

Handles

PP handles.

Lighting equipment

40W*2 antisepsis daylight lamp, lamp house is insulated with gas.

Lightness on table not lower than 400LUX.

Operation panel

lighting switch, ON/OFF switch, two sets of 220V/10A versatile electric socket

Ventilation equipment

Selecting rust-resistance, low wasting, low noise and famous fan and special wind tube. Noise can be reduced at about 55 DB

Cubage

20L

Ext. sizes(H*W*D)

2400×1800×800mm

Operation table size(H*W*D)

1100×1600×700mm

Accessory

Vertical and single test cock: made by brass, the surface is treated by EPOXY baking paint.

Cup slot: acid and alkali resistance, PP water cup.

Sink: PP cup sink.

Socket: multi-functional with splash-proof box and safeguard cover.

Warranty

One year

Application

PFH series Fume hoods are the first defense to minimize dangerous chemical exposure to research workers. They are considered the primary means of protection from inhalation of hazardous vapors.



Chemical fume hood Details:



8mm Polypropylene Lab Fume Hood Rust-Resistance Pfh High capacity for corrosive substance 0

8mm Polypropylene Lab Fume Hood Rust-Resistance Pfh High capacity for corrosive substance 1



8mm Polypropylene Lab Fume Hood Rust-Resistance Pfh High capacity for corrosive substance 2







Description PFH6-120 PFH6-150 PFH6-180
Overall Size (With Base Cabinet) (H×W×D) 2400x1200x850mm 2400x1500x850mm 2400x1800x850mm
Working Area(H×W×D) 1100x1000x700mm 1100x1300x700mm 1100x1600x700mm
Base cabinet (H×W×D) 850 x1200x850mm
Work Platform Main Unit - 100%, 8 mm PP fabricated.
Construction Material Main Unit - 100%, 8 mm PP fabricated.
Window Made of 5mm tempered glass, max:820mm opening
Power supply
Touch control panel
AC220V10A ON/OFF Switches on front fascia (BL / FL) A fluorescent lamp, fan, the power switch and stand-by switch
Air Flow 100 % Air take from inside room through
Remote control water valve Pure water, tap-water
Remote control air valve One N2 valve, one vacuum valve
Water Tank One
Options and Accessories:

A wide range of configurations to suit any containment application: -

Base Cabinet with chemical storage cabinet (with air vent)

Sink : Molded polypropylene sink with drain nipple

Auxiliary Socket – 5/15 Amp. – As require qty.

Filter chocking alarms , Universal Casters with Brake

OTHER CAPACITY : ON REQUEST
