8mm Polypropylene Lab Fume Hood Rust-Resistance Pfh High capacity for corrosive substance

8mm Polypropylene Lab Fume Hood Rust-Resistance Pfh High capacity for corrosive substance

    • 8mm Polypropylene Lab Fume Hood Rust-Resistance Pfh High capacity for corrosive substance
    • 8mm Polypropylene Lab Fume Hood Rust-Resistance Pfh High capacity for corrosive substance
    • 8mm Polypropylene Lab Fume Hood Rust-Resistance Pfh High capacity for corrosive substance
    • 8mm Polypropylene Lab Fume Hood Rust-Resistance Pfh High capacity for corrosive substance
    • 8mm Polypropylene Lab Fume Hood Rust-Resistance Pfh High capacity for corrosive substance
  • 8mm Polypropylene Lab Fume Hood Rust-Resistance Pfh High capacity for corrosive substance

    Product Details:

    Place of Origin: CHINA
    Brand Name: SOPERSL
    Certification: ISO9001
    Model Number: PFH6-1800

    Payment & Shipping Terms:

    Minimum Order Quantity: 5
    Price: Negotiation
    Packaging Details: crate box
    Delivery Time: 25-30 Days
    Payment Terms: T/T or L/C at sight
    Supply Ability: 1500 per month
    Contact Now
    Detailed Product Description
    Color: White Noise DBA: ≤ 60
    Blower: Built-in Centrifugal Fan Material: Poly
    Name: Chemical Fume Hood

    8mm Polypropylene Lab Fume Hood Rust-Resistance Pfh High capacity







    Production Description

    • 8mm.Polypropylene material
    • polypropylene, acid and alkali resistance, temperature- resistance, anti-moisture
    • Easy: install and wash.
    • strong bearing capacity.

    Name

    Value

    Brand

    SOPERSL

    Model

    PFH6-180

    Window

    5mm PS transparent plate, balancing form elevation and subsidence, it can be stopped at any position by pulling.

    Handles

    PP handles.

    Lighting equipment

    40W*2 antisepsis daylight lamp, lamp house is insulated with gas.

    Lightness on table not lower than 400LUX.

    Operation panel

    lighting switch, ON/OFF switch, two sets of 220V/10A versatile electric socket

    Ventilation equipment

    Selecting rust-resistance, low wasting, low noise and famous fan and special wind tube. Noise can be reduced at about 55 DB

    Cubage

    20L

    Ext. sizes(H*W*D)

    2400×1800×800mm

    Operation table size(H*W*D)

    1100×1600×700mm

    Accessory

    Vertical and single test cock: made by brass, the surface is treated by EPOXY baking paint.

    Cup slot: acid and alkali resistance, PP water cup.

    Sink: PP cup sink.

    Socket: multi-functional with splash-proof box and safeguard cover.

    Warranty

    One year

    Application

    PFH series Fume hoods are the first defense to minimize dangerous chemical exposure to research workers. They are considered the primary means of protection from inhalation of hazardous vapors.



    Chemical fume hood Details:



    8mm Polypropylene Lab Fume Hood Rust-Resistance Pfh High capacity for corrosive substance

    8mm Polypropylene Lab Fume Hood Rust-Resistance Pfh High capacity for corrosive substance



    8mm Polypropylene Lab Fume Hood Rust-Resistance Pfh High capacity for corrosive substance







    Description PFH6-120 PFH6-150 PFH6-180
    Overall Size (With Base Cabinet) (H×W×D) 2400x1200x850mm 2400x1500x850mm 2400x1800x850mm
    Working Area(H×W×D) 1100x1000x700mm 1100x1300x700mm 1100x1600x700mm
    Base cabinet (H×W×D) 850 x1200x850mm
    Work Platform Main Unit - 100%, 8 mm PP fabricated.
    Construction Material Main Unit - 100%, 8 mm PP fabricated.
    Window Made of 5mm tempered glass, max:820mm opening
    Power supply
    Touch control panel
    AC220V10A ON/OFF Switches on front fascia (BL / FL) A fluorescent lamp, fan, the power switch and stand-by switch
    Air Flow 100 % Air take from inside room through
    Remote control water valve Pure water, tap-water
    Remote control air valve One N2 valve, one vacuum valve
    Water Tank One
    Options and Accessories:

    A wide range of configurations to suit any containment application: -

    Base Cabinet with chemical storage cabinet (with air vent)

    Sink : Molded polypropylene sink with drain nipple

    Auxiliary Socket – 5/15 Amp. – As require qty.

    Filter chocking alarms , Universal Casters with Brake

    OTHER CAPACITY : ON REQUEST
